規格型號：52838708
頻率：30M
尺寸：7050mm
PDF
產品描述：12.94437晶振,KXO-V97T振蕩器,Geyer格耶有源晶振,采用SMD貼片封裝,體積小巧,適配高密度PCB板設計,滿足小型化電子設備的安裝需求.可廣泛應用于網絡通信,智能儀表,汽車電子等領域.

12.94437晶振,KXO-V97T振蕩器,Geyer格耶有源晶振

Geyer格耶電子晶振系列之12.94437MHz型號,搭載KXO-V97T振蕩器核心模塊,憑借品牌成熟的有源驅動技術,實現超低功耗運行與卓越的頻率一致性.產品支持寬電壓輸入范圍,工作溫度覆蓋-40℃至85℃,適配惡劣工業環境與戶外設備應用.封裝工藝精密,抗振動,抗沖擊性能優異,可直接為FPGA,MCU等核心芯片提供精準時鐘信號,簡化電路設計流程.

12.94437晶振,KXO-V97T振蕩器,Geyer格耶有源晶振

原廠型號 Originalmodel：	12.94437	品牌brand：	Geyer
Manufacturer品牌	Geyer	OperatingTemperature溫度	-40+85℃
Series型號	KXO-V97T	Current-Supply(Max)	-
Type類型	XO	PackageHeight高度	1.3mm
Frequency頻率	30M	Termination 腳位	4-pad
輸出方式 Output：	CMOS	PackageType 封裝類型	4-smd
Voltage-Supply電壓	3.3V	Packaging 包裝	TapeandReel
FrequencyStability頻率穩定度	±100ppm	安裝方式 Installation：	Surfacemount
Size/Dimension尺寸	7050mm振蕩器	最小包裝數MPQ：	1000

12.94437晶振,KXO-V97T振蕩器,Geyer格耶有源晶振

12.94437晶振,KXO-V97T振蕩器,Geyer格耶有源晶振

12.73000	KXO-V93	1.6 \| 1.2 \| 0.6 mm	20.0 MHz	-40°C to +85°C
12.73001	KXO-V93	1.6 \| 1.2 \| 0.6 mm	24.0 MHz	-40°C to +85°C
12.73002	KXO-V93	1.6 \| 1.2 \| 0.6 mm	40.0 MHz	-40°C to +85°C
12.73003	KXO-V93	1.6 \| 1.2 \| 0.6 mm	50.0 MHz	-40°C to +85°C
12.73004	KXO-V93	1.6 \| 1.2 \| 0.6 mm	48.0 MHz	-40°C to +85°C
12.73005	KXO-V93	1.6 \| 1.2 \| 0.6 mm	8.0 MHz	-40°C to +85°C
12.73006	KXO-V93	1.6 \| 1.2 \| 0.6 mm	3.68640 MHz	-40°C to +85°C
12.73007	KXO-V93	1.6 \| 1.2 \| 0.6 mm	16.0 MHz	-40°C to +85°C
12.73008	KXO-V93	1.6 \| 1.2 \| 0.6 mm	25.0 MHz	-40°C to +85°C
12.73009	KXO-V93	1.6 \| 1.2 \| 0.6 mm	24.0 MHz	-40°C to +85°C
12.73010	KXO-V93	1.6 \| 1.2 \| 0.6 mm	8.0 MHz	-40°C to +85°C
12.73011	KXO-V93	1.6 \| 1.2 \| 0.6 mm	3.68640 MHz	-40°C to +85°C
12.73012	KXO-V93	1.6 \| 1.2 \| 0.6 mm	16.0 MHz	-40°C to +85°C
12.73013	KXO-V93	1.6 \| 1.2 \| 0.6 mm	25.0 MHz	-40°C to +85°C
12.73014	KXO-V93	1.6 \| 1.2 \| 0.6 mm	12.0 MHz	-40°C to +85°C
12.73015	KXO-V93	1.6 \| 1.2 \| 0.6 mm	27.0 MHz	-40°C to +85°C
12.73016	KXO-V93	1.6 \| 1.2 \| 0.6 mm	19,20 MHz	-40°C to +85°C
12.73017	KXO-V93	1.6 \| 1.2 \| 0.6 mm	12.2880 MHz	-40°C to +85°C
12.73018	KXO-V93	1.6 \| 1.2 \| 0.6 mm	12.0 MHz	-40°C to +85°C
12.73019	KXO-V93	1.6 \| 1.2 \| 0.6 mm	27.120 MHz	-40°C to +85°C
12.73021	KXO-V93	1.6 \| 1.2 \| 0.6 mm	32.7680 MHz	-40°C to +85°C
12.73022	KXO-V93	1.6 \| 1.2 \| 0.6 mm	12.0 MHz	-40°C to +85°C
12.73023	KXO-V93	1.6 \| 1.2 \| 0.6 mm	13.560 MHz	-40°C to +85°C
12.90000	KXO-200	20.8 \| 13.2 \| 5.08 mm	1.0 MHz	-20°C to +70°C
12.90013	KXO-200	20.8 \| 13.2 \| 5.08 mm	14.187570 MHz	-20°C to +70°C
12.90045	KXO-200	20.8 \| 13.2 \| 5.08 mm	33.0 MHz	-20°C to +70°C
12.90101	KXO-200	20.8 \| 13.2 \| 5.08 mm	1.84320 MHz	-20°C to +70°C
12.90121	KXO-200	20.8 \| 13.2 \| 5.08 mm	12.0 MHz	-20°C to +70°C
12.90124	KXO-200	20.8 \| 13.2 \| 5.08 mm	14.318180 MHz	-20°C to +70°C
12.90126	KXO-200	20.8 \| 13.2 \| 5.08 mm	16.0 MHz	-20°C to +70°C
12.90147	KXO-200	20.8 \| 13.2 \| 5.08 mm	5.0 MHz	-20°C to +70°C
12.90149	KXO-200	20.8 \| 13.2 \| 5.08 mm	80.0 MHz	-20°C to +70°C
12.90150	KXO-200	20.8 \| 13.2 \| 5.08 mm	48.0 MHz	-20°C to +70°C
12.90151	KXO-200	20.8 \| 13.2 \| 5.08 mm	50.0 MHz	-20°C to +70°C
12.90240	KXO-400	20.8 \| 13.2 \| 5.08 mm	20.0 MHz	-20°C to +70°C
12.90300	KXO-V94	2.0 \| 1.6 \| 0.8 mm	27.0 MHz	-20°C to +70°C
12.90301	KXO-V94	2.0 \| 1.6 \| 0.8 mm	1.0 MHz	-40°C to +85°C
12.90302	KXO-V94	2.0 \| 1.6 \| 0.8 mm	8.0 MHz	-40°C to +85°C
12.90303	KXO-V94	2.0 \| 1.6 \| 0.8 mm	3.68640 MHz	-40°C to +85°C
12.90304	KXO-V94	2.0 \| 1.6 \| 0.8 mm	25.0 MHz	-40°C to +85°C
12.90305	KXO-V94	2.0 \| 1.6 \| 0.8 mm	20.0 MHz	-20°C to +70°C
12.90306	KXO-V94	2.0 \| 1.6 \| 0.8 mm	14.0 MHz	-20°C to +70°C
12.90307	KXO-V94	2.0 \| 1.6 \| 0.8 mm	1.84320 MHz	-40°C to +85°C
12.90308	KXO-V94	2.0 \| 1.6 \| 0.8 mm	3.68640 MHz	-20°C to +70°C
12.90309	KXO-V94	2.0 \| 1.6 \| 0.8 mm	25.0 MHz	-20°C to +70°C
12.90310	KXO-V94	2.0 \| 1.6 \| 0.8 mm	1.84320 MHz	-20°C to +70°C
12.90311	KXO-V94	2.0 \| 1.6 \| 0.8 mm	14.74560 MHz	-40°C to +85°C
12.90312	KXO-V94	2.0 \| 1.6 \| 0.8 mm	40.0 MHz	-40°C to +85°C
12.90313	KXO-V94	2.0 \| 1.6 \| 0.8 mm	40.0 MHz	-20°C to +70°C
12.90314	KXO-V94	2.0 \| 1.6 \| 0.8 mm	19,20 MHz	-40°C to +85°C
12.90315	KXO-V94	2.0 \| 1.6 \| 0.8 mm	20.0 MHz	-40°C to +85°C
12.90316	KXO-V94	2.0 \| 1.6 \| 0.8 mm	26.0 MHz	-40°C to +85°C
12.90317	KXO-V94	2.0 \| 1.6 \| 0.8 mm	38.40 MHz	-40°C to +85°C
12.90318	KXO-V94	2.0 \| 1.6 \| 0.8 mm	40.0 MHz	-40°C to +85°C
12.90319	KXO-V94	2.0 \| 1.6 \| 0.8 mm	52.0 MHz	-40°C to +85°C
12.90320	KXO-V94	2.0 \| 1.6 \| 0.8 mm	27.0 MHz	-40°C to +85°C
12.90321	KXO-V94	2.0 \| 1.6 \| 0.8 mm	14.74560 MHz	-40°C to +85°C
12.90322	KXO-V94	2.0 \| 1.6 \| 0.8 mm	20.0 MHz	-40°C to +85°C
12.90323	KXO-V94	2.0 \| 1.6 \| 0.8 mm	25.0 MHz	-40°C to +85°C
12.90324	KXO-V94	2.0 \| 1.6 \| 0.8 mm	27.0 MHz	-40°C to +85°C
